| 品牌：ABB | 型号：普通晶闸管 | 封装：压接式 |
| 批号：100001 |
| Part Number | VDRM (V) | ITAV (A) | ITSM (kA) | Package* (mm) |
|---|---|---|---|---|
| 5STP 07D1800 | 1800 | 760 | 9.0 | 60/34 |
| 5STP 18F1800 | 1800 | 1780 | 21.0 | 75/47 |
| 5STP 27H1800 | 1800 | 2940 | 50.5 | 102/63 |
| 5STP 42L1800 | 1800 | 4310 | 64.0 | 120/78 |
| 5STP 50Q1800 | 1800 | 6100 | 94.0 | 150/100 |
| 5STP 06D2800 | 2800 | 640 | 8.8 | 60/34 |
| 5STP 16F2800 | 2800 | 1500 | 18.0 | 75/47 |
| 5STP 24H2800 | 2800 | 2780 | 43.0 | 102/63 |
| 5STP 33L2800 | 2800 | 3760 | 65.5 | 120/78 |
| 5STP 45N2800 | 2800 | 5250 | 77.0 | 150/100 |
| 5STP 45Q2800 | 2800 | 5710 | 77.0 | 150/100 |
| 5STP 04D4200 | 4200 | 500 | 7.1 | 60/34 |
| 5STP 12F4200 | 4200 | 1190 | 17.3 | 75/47 |
| 5STP 18H4200 | 4200 | 2170 | 32.0 | 102/63 |
| 5STP 28L4200 | 4200 | 3290 | 54.0 | 120/78 |
| 5STP 38N4200 | 4200 | 4090 | 64.5 | 150/100 |
| 5STP 38Q4200 | 4200 | 4420 | 64.5 | 150/100 |
| 5STP 04D5200 | 5200 | 420 | 6.1 | 60/34 |
| 5STP 17H5200 | 5200 | 1970 | 34.0 | 102/63 |
| 5STP 25L5200 | 5200 | 2830 | 50.5 | 120/78 |
| 5STP 25M5200 | 5200 | 2400 | 50.5 | 120/78 |
| 5STP 34N5200 | 5200 | 3450 | 63.0 | 150/100 |
| 5STP 34Q5200 | 5200 | 3720 | 63.0 | 150/100 |
| 5STP 52U5200 | 5200 | 5200 | 99.0 | 172/110 |
| 5STP 03X6500 | 6500 | 340 | 4.7 | 60/34 |
| 5STP 03D6500 | 6500 | 390 | 4.7 | 60/34 |
| 5STP 08F6500 | 6500 | 850 | 15.1 | 75/47 |
| 5STP 08G6500 | 6500 | 730 | 15.1 | 75/47 |
| 5STP 12K6500 | 6500 | 1430 | 31.5 | 102/63 |
| 5STP 18M6500 | 6500 | 1830 | 47.5 | 120/78 |
| 5STP 26N6500 | 6500 | 2880 | 65.0 | 150/100 |
| 5STP 40N6500 # New | 6500 | 3780 | 75.0 | 150/100 |
| 5STP 42U6500 | 6500 | 4300 | 86.0 | 172/110 |
| 5STP 48Y7200 | 7200 | 5040 | 92.0 | 192/138 |
| 5STP 27N8500 | 8500 | 2660 | 64.0 | 150/100 |
| 5STP 27Q8500 | 8500 | 2870 | 64.0 | 150/100 |
| 5STP 45Y8500 | 8500 | 4450 | 90.0 | 192/138 |
